| 产地：江苏 | 是否进口：否 | 订货号：5945544156 |
| 品牌：理士 | 货号：15648946 | 型号：DJM1238 |
| 化学类型：铅酸蓄电池 | 电压：12V | 类型：储能用蓄电池 |
| 荷电状态：免维护蓄电池 | 电池盖和排气拴结构：阀控式密闭蓄电池 | 额定容量：24AH |
| 外型尺寸：151*95*62mm | 产品认证：TUV | 适用范围：ups蓄电池 |
| 是否跨境货源：否 |
电池型号 Battery Model | 额定电压Voltage (V) | 额定容量Nominal Capacity (AH) | 外形尺寸Dimension (mm) | 端子形式Terminal | |||||||
20HR | 10HR | 5HR | 3HR | 1HR | 长 | 宽 | 高 | 总高 | |||
1.80V/Cell | 1.80V/Cell | 1.75V/Cell | 1.75V/Cell | 1.67V/Cell | Length | Width | Height | Total Height | |||
DJM1238 | 12 | 40.2 | 38.0 | 33.3 | 30.3 | 23.4 | 197±2 | 165±1 | 170±1 | 170±1 | T6 |
DJM1240 | 12 | 42.4 | 40.0 | 35.0 | 31.8 | 24.6 | 197±2 | 165±1 | 170±1 | 170±1 | T6 |
DJM1245 | 12 | 47.8 | 45.0 | 39.4 | 35.7 | 27.7 | 197±2 | 165±1 | 170±1 | 170±1 | T6 |
DJM1250 | 12 | 53.0 | 50.0 | 43.8 | 39.9 | 30.8 | 257±2 | 132±1 | 200±2 | 200±2 | T6 |
DJM1255 | 12 | 58.4 | 55.0 | 48.2 | 43.8 | 33.8 | 229±2 | 138±1 | 205±2 | 226±2 | T6 |
DJM1260 | 12 | 63.6 | 60.0 | 52.5 | 47.7 | 36.9 | 259±2 | 168±1 | 208±2 | 214±2 | T6 |
DJM1265 | 12 | 69.0 | 65.0 | 57.0 | 51.6 | 40.0 | 348±3 | 167±1 | 178±1 | 178±1 | T6 |
DJM1275 | 12 | 79.6 | 75.0 | 65.5 | 59.7 | 46.1 | 348±3 | 167±1 | 178±1 | 178±1 | T6 |
DJM1275H | 12 | 79.6 | 75.0 | 65.5 | 59.7 | 46.1 | 259±2 | 168±1 | 208±2 | 230±2 | T6 |
DJM1280 | 12 | 84.8 | 80.0 | 70.0 | 63.6 | 49.2 | 259±2 | 168±1 | 208±2 | 214±2 | T6 |
DJM1290 | 12 | 95.4 | 90.0 | 79.0 | 71.7 | 55.4 | 330±3 | 173±1 | 212±2 | 220±2 | T11 |
DJM1290H | 12 | 95.4 | 90.0 | 79.0 | 71.7 | 55.4 | 305±3 | 168±1 | 207±2 | 213±2 | T6 |
DJM12100 | 12 | 106 | 100 | 87.5 | 79.5 | 61.5 | 330±3 | 173±1 | 212±2 | 220±2 | T11 |
DJM12120 | 12 | 127 | 120 | 105 | 95.4 | 73.8 | 410±3 | 177±1 | 225±2 | 225±2 | T11 |
DJM12140 | 12 | 148 | 140 | 123 | 111 | 86.1 | 344±3 | 171±1 | 274±2 | 280±2 | T11 |
DJM12150 | 12 | 159 | 150 | 132 | 119 | 92.3 | 485±3 | 170±1 | 240±2 | 240±2 | T11 |
DJM12180 | 12 | 191 | 180 | 158 | 143 | 111 | 530±3 | 209±2 | 214±2 | 220±2 | T11 |
DJM12200 | 12 | 212 | 200 | 175 | 159 | 123 | 522±3 | 240±2 | 218±2 | 224±2 | T11 |
DJM12230 | 12 | 244 | 230 | 202 | 183 | 141 | 522±3 | 240±2 | 218±2 | 224±2 | T11 |
DJM12250 | 12 | 266 | 250 | 219 | 199 | 154 | 522±3 | 268±2 | 220±2 | 226±2 | T11 |
